Real-time UI
Function calling described at the previous section gives an unlimited possibilities to create interactive applications that can be controlled by LLMs, executing back-end functions either at the current context (via controller modules) or thru HTTP protocol via RPC modules. This article describes one of use-cases of this feature - building a real-time UI that can be updated by LLMs with a text chat or voice interface.
In order to demonstrate this feature, I’ve created a demo project of a kanban board that you can find at GitHub repository . The database is going to have only two tables: users and tasks. Note that the described project is just a demo and might need additional optimizations and improvements to be used in production.
Here’s how you can install and run it locally:
Clone the repository:
git clone https://github.com/finom/vovk-ai-demo.gitInstall the dependencies:
yarnCreate a .env file in the root directory and add your OpenAI API key and database connection strings:
OPENAI_API_KEY=change_me
DATABASE_URL="postgresql://postgres:password@localhost:5432/vovk-ai-demo-db?schema=public"
DATABASE_URL_UNPOOLED="postgresql://postgres:password@localhost:5432/vovk-ai-demo-db?schema=public"
REDIS_URL=redis://localhost:6379Run docker containers and development server
docker-compose up -d && yarn devOpen http://localhost:3000 with your browser to see the result.
Overview
At this article I’m going to describe an efficient way to synchronise application state with the back-end data, that can be applied to any application even if it isn’t using Vovk.ts at all. This idea is state library-agnostic and database-agnostic, so you can implement it with any tools you prefer. I’m going to use Postgres as a database, Prisma as an ORM, Zustand as a state management library and, of course Vovk.ts as a back-end framework.
Let’s say we have an more or less complex application with multiple components that use the same data that’s incoming from the server. As the most simple example imaginable, we have a user profile component that displays displays user’s full name at multiple components. Once the data is updated we want to update all the components that use this data.
Update your profile, John Doe!
The most straightforward way to do this is to have a global state that stores the user profile as an object and update it once the data is changed.
export const UserProfile = () => {
const { userProfile } = useStore();
return <div>{userProfile.fullName}</div>
}This works perfectly fine for up to a certain complexity of the application, but as the application grows and more database entries are added, it becomes harder to manage the state and keep it in sync with the server.
A more efficient way to handle this is to have a normalized state that stores the data as a dictionary of objects, where the key is the ID of the object. This way, we can easily update a single object and all the components that use this object will be updated automatically. Let’s call it entity registry.
export const UserProfile = ({ userId }: { userId: string }) => {
const userProfile = useStore(state => state.userProfiles[userId]);
return <div>{userProfile.fullName}</div>
}If all components that use database data are using this approach, we can request the data from the server in any desired way and update the entity registry once the data is received by a some kind of a middleware. All components that use this data will be updated automatically.
Let’s get back to the kanban board example.
WebRTC-based Voice AI
As setting up real-time API from OpenAI is quite tricky, I’ve borrowed most of the code from repository created by Cameron King . In short, the code authorizes the WebRTC connection in a separate controller , and then establishes a peer-to-peer connection with OpenAI Realtime API, sending audio data from the microphone and receiving text and audio responses. The original hooks, such as useToolsFunctions and useWebRTCAudioSession, are left as is, with only a few minor changes.
Designing the database
The only requirement that we’ve got to perform is to make server return entities that include entity type (besides the ID) so that the middleware can understand where this entity should be stored in the registry. In our case we have two entities: users and tasks. For this we’re going to create an enum with lower-cased entity names in singular form and add it to each table as a column with a default value.
We’re also going to use prisma-zod-generator to generate Zod schemas from our Prisma models. This will help us to define Zod models automatically and make our code much shorter.
// ...
generator zod {
provider = "prisma-zod-generator"
config = "./zod-generator.config.json"
}
model User {
/// @zod.custom.use(z.uuid().brand<Extract<z.infer<typeof EntityTypeSchema>, 'user'>>())
id String @id @default(uuid())
/// @zod.custom.use(z.literal('user'))
entityType EntityType @default(user)
// ... other fields ...
tasks Task[]
}
model Task {
/// @zod.custom.use(z.uuid().brand<Extract<z.infer<typeof EntityTypeSchema>, 'task'>>())
id String @id @default(uuid())
/// @zod.custom.use(z.literal('task'))
entityType EntityType @default(task)
// ... other fields ...
/// @zod.custom.use(z.string().uuid().brand<Extract<z.infer<typeof EntityTypeSchema>, 'user'>>())
userId String
user User @relation(fields: [userId], references: [id])
}
enum EntityType {
user
task
}Check the full schema at the GitHub repository .
Notice the triple slashes comments. As the app is going to work with entity IDs, we need to distinguish between IDs of different entity types implemented as branded types. We’re also using branded types for entityType column, turning them into literals.
That’s it. Each time when you invoke npx prisma generate, the Zod schemas are going to be generated automatically at src/prisma/generated folder with all the necessary type specifics.
Setting up the back-end
As we’re going to use function calling we’re going to apply a workaround decribed at Zod / Trobleshooting that allows to generate JSON schemas from Zod using draft-07 version by creating withZod helper function with createStandardValidation that creates a validation library with Standard Schema.
import { z } from 'zod';
import { createStandardValidation } from 'vovk';
export const withZod = createStandardValidation({
toJSONSchema: (model: z.core.$ZodType) => z.toJSONSchema(model, { target: 'draft-7' }),
});For additional type safety, let’s create a BaseEntity interface that describes the base fields of all entities in the database for additional type checking.
import { EntityType } from "@prisma/client";
export interface BaseEntity {
id: string;
createdAt: string | Date;
updatedAt: string | Date;
entityType: EntityType;
}For the sake of simplicity, we also need to create a reusable constant BASE_FIELDS that is going to be used to omit id, entityType, createdAt and updatedAt fields from the input models.
export const BASE_FIELDS = {
id: true,
entityType: true,
createdAt: true,
updatedAt: true,
} as const;At this case we can easily get the update models by omitting these fields from the generated Zod schemas.
import { UserSchema } from "../../../prisma/generated/schemas";
import { BASE_FIELDS } from "../../../constants";
const UpdateUserSchema = UserSchema.omit(BASE_FIELDS);The controllers and services are quite self-explanatory: we decorate each method with @operation decorator, and create handlers with withZod function. They have some additional features that will be described later:
- @operation decorator accepts
x-tool-successMessageandx-tool-errorMessageused for MCP responses, described at the MCP article. - Database requests are invoked using
DatabaseService.prismawhere theprismaproperty is a normal Prisma client instance with extensions . One of the features relevant to this article is that it adds__isDeletedproperty to the deleted entities whenprisma.xxx.deletemethod is invoked. Rest of the features will be described at polling article.
Task controller and service implemented in the same way.
Setting up the application state
As we’ve discussed above, the application state is going to be normalized and store entities in a dictionary by their IDs. The registry is going to have a parse method that accepts any data and extracts entities from it, storing them in the registry. The method is going to be used to process all incoming data from the server, so that all components that use this data are going to be updated automatically.
import { EntityType } from "@prisma/client";
import { create } from "zustand";
import fastDeepEqual from "fast-deep-equal";
import type { BaseEntity } from "./types";
import type { UserType } from "../prisma/generated/schemas/models/User.schema";
import type { TaskType } from "../prisma/generated/schemas/models/Task.schema";
interface Registry {
parse: (data: unknown) => Partial<{
[key in EntityType]: BaseEntity[];
}>;
}
function getEntitiesFromResponse(
data: unknown,
entities: Partial<{ [key in EntityType]: BaseEntity[] }> = {},
) {
if (Array.isArray(data)) {
data.forEach((item) => getEntitiesFromResponse(item, entities));
} else if (typeof data === "object" && data !== null) {
Object.values(data).forEach((value) =>
getEntitiesFromResponse(value, entities),
);
if ("entityType" in data && "id" in data) {
const entityType = data.entityType as EntityType;
entities[entityType] ??= [];
entities[entityType].push(data as BaseEntity);
}
}
return entities;
}
const synced: Partial<Record<EntityType, boolean>> = {};
export const useRegistry = create<Registry>((set, get) => ({
[EntityType.user]: {},
[EntityType.task]: {},
parse: (data) => {
const entities = getEntitiesFromResponse(data);
set((state) => {
const newState: Record<string, unknown> = {};
Object.entries(entities).forEach(([entityType, entityList]) => {
const type = entityType as EntityType;
const descriptors = Object.getOwnPropertyDescriptors(state[type] ?? {});
entityList.forEach((entity) => {
descriptors[entity.id] =
descriptors[entity.id]?.value &&
fastDeepEqual(descriptors[entity.id]?.value, entity)
? descriptors[entity.id]
: ({
value: { ...descriptors[entity.id]?.value, ...entity },
configurable: true,
writable: false,
} satisfies PropertyDescriptor);
descriptors[entity.id].enumerable = !("__isDeleted" in entity);
});
newState[type] = Object.defineProperties({}, descriptors);
});
const resultState = { ...state, ...newState };
return resultState;
});
return entities;
},
}));The code is small but quite complex, so let’s break it down:
getEntitiesFromResponse is a recursive function that extracts entities from any data structure, based on the presence of entityType and id properties. Let’s say the server returns the following response:
{
"tasks": [
{
"id": "task-1",
"title": "Task 1",
"entityType": "task",
"user": {
"id": "user-1",
"fullName": "John Doe",
"entityType": "user"
}
},
{
"id": "task-2",
"title": "Task 2",
"entityType": "task",
"user": {
"id": "user-2",
"fullName": "Jane Doe",
"entityType": "user"
}
}
]
}The function is going to walk thru the entire object and extract all entities, turning the object into a preliminary format and not modifying the original database objects:
{
"task": [
{ "id": "task-1", "title": "Task 1", "entityType": "task", "user": { /* stays the same */ } },
{ "id": "task-2", "title": "Task 2", "entityType": "task", "user": { /* stays the same */ } }
],
"user": [
{ "id": "user-1", "fullName": "John Doe", "entityType": "user" },
{ "id": "user-2", "fullName": "Jane Doe", "entityType": "user" }
]
}Now let’s take our thinking hat on and break down the useRegistry store created by create function from Zustand.
First two bits such as [EntityType.user]: {} and [EntityType.task]: {} are the objects where the entities are going to be stored, with entity IDs as keys.
The third bit is the parse method that accepts any data, extracts entities from it and stores them in the registry. That’s where the magic happens. Instead of simply extending the state with new entities, we’re using Object.getOwnPropertyDescriptors to get the property descriptors of the existing entities. This way we can check if the entity already exists in the state and if it does, we can compare it with the new entity using fast-deep-equal library. If the entities are equal, we don’t update the state, otherwise we create a new property descriptor with the updated entity. This way we can avoid unnecessary re-renders of the components that use this entity. The __isDeleted property is used to mark entities as deleted without actually removing them from the state, avoiding errors in components that might still reference them. Once __isDeleted is received (see service code above), the property descriptor is marked as non-enumerable, so it won’t be included in Object.values or Object.keys calls, making the entity effectively invisible.
That’s it. Each time when the data is received from the server, it needs to go thru the parse method of the registry, and all components that use the data are going to be updated automatically.
Setting up the fetcher
The last piece of the puzzle is to create a fetcher function (mentioned above as a “middleware”) that is going to be used by the application to request data from the server. You can find more details about it at imports article.
The fetcher is going to implement transformResponse function that is going to process all incoming data, passing it to the parse method of the registry. The function is also going to handle both regular JSON data and async iterables (if you use JSONLines responses).
import { useRegistry } from "@/registry";
import { createFetcher } from "vovk";
export const fetcher = createFetcher({
transformResponse: async (data) => {
const state = useRegistry.getState();
if (
data && typeof data === "object" &&
Symbol.asyncIterator in data &&
"onIterate" in data &&
typeof data.onIterate === "function"
) {
data.onIterate(state.parse); // handle each item in the async iterable
return data;
}
state.parse(data); // parse regular JSON data
return data;
},
});Declare the fetcher in the config. It will replace the default fetcher imported by the generated client.
// @ts-check
/** @type {import('vovk').VovkConfig} */
const config = {
generatorConfig: {
imports: {
// ...
fetcher: "./src/lib/fetcher.ts",
},
}
};
export default config;That’s it. From now on, each request is going to be processed by the registry parse method, and manual response handling is not required anymore.
import { useShallow } from "zustand/shallow";
import { useQuery } from "@tanstack/react-query";
import { UserRPC } from "vovk-client";
import { useRegistry } from "@/registry";
import { UserType } from "../../prisma/generated/schemas/models/User.schema";
interface Props {
userIds: UserType["id"][]; // an array of branded user IDs
}
const UsersExample = ({ userIds }: Props) => {
useQuery({
queryKey: UserRPC.getUsers.queryKey(),
queryFn: () => UserRPC.getUsers(),
});
const users = useRegistry(
useShallow((state) => userIds.map((id) => state.user[id])),
);
return <div>
<ul>
{users.map((user) => (
<li key={user.id}>{user.fullName}</li>
))}
</ul>
</div>;
};
export default UsersExample;As you can see useQuery invocation doesn’t require to use data property anymore, as the response is processed by the registry automatically. The invocation of UserRPC.getUsers() or any other server-side method (with useQuery or without) can be placed anywhere in the app, and all components that use user data are going to be updated automatically.
Final bit: enabling function calling
As Cameron King provided a solid framework for Next.js + OpenAI Realtime API + Function Calling, the only thing left is to extend or replace existing tools with createLLMTools function from Vovk.ts, that turns RPC modules into tools that can be used by any LLM setup.
"use client";
import { useToolsFunctions } from "@/hooks/use-tools";
import useWebRTCAudioSession from "@/hooks/use-webrtc";
import { tools } from "@/lib/tools"; // default tools by Cameron King
import { useEffect, useState } from "react";
import { createLLMTools } from "vovk";
import { TaskRPC, UserRPC } from "vovk-client";
import Floaty from "./Floaty";
const { tools: llmTools } = createLLMTools({
modules: { TaskRPC, UserRPC },
});
const RealTimeDemo = () => {
// State for voice selection
const [voice] = useState<"ash" | "ballad" | "coral" | "sage" | "verse">(
"ash",
);
// WebRTC Audio Session Hook
const {
isSessionActive,
registerFunction,
handleStartStopClick,
currentVolume,
} = useWebRTCAudioSession(voice, [...tools, ...llmTools]);
// Get all tools functions
const toolsFunctions = useToolsFunctions();
useEffect(() => {
// Register all functions by iterating over the object
Object.entries(toolsFunctions).forEach(([name, func]) => {
const functionNames: Record<string, string> = {
timeFunction: "getCurrentTime",
partyFunction: "partyMode",
scrapeWebsite: "scrapeWebsite",
};
registerFunction(functionNames[name], func);
});
// Register all LLM tools functions
llmTools.forEach(({ name, execute }) => {
registerFunction(name, execute);
});
}, [registerFunction, toolsFunctions]);
return (
<div>
<Floaty
isActive={isSessionActive}
volumeLevel={currentVolume}
handleClick={handleStartStopClick}
/>
</div>
);
};
export default RealTimeDemo;For more details, check the full code of the component at the GitHub repository that imports the Floaty component .
